Duo Single Sign-On for Cisco Webex (with Control Hub)

Last Updated: October 6th, 2020

Add two-factor authentication and flexible security policies to Cisco Webex SSO logins with Duo Single-Sign On, our cloud-hosted SAML 2.0 identity provider, complete with inline self-service enrollment and Duo Prompt.

If your administrator login URL is https://admin.webex.com/login continue below. If your administrator login URL for Cisco Webex is https://yourdomain.webex.com/admin, please see our generic service provider application.

These Webex clients support Trusted Endpoints:

  • Webex Meetings on Windows and macOS
  • Webex Teams 3.0.12427.0 and later on macOS with the Duo Certifier for macOS installed
  • Webex Teams 3.0.12427.0 and later on Windows

Overview

As business applications move from on-premises to cloud hosted solutions, users experience password fatigue due to disparate logons for different applications. Single sign-on (SSO) technologies seek to unify identities across systems and reduce the number of different credentials a user has to remember or input to gain access to resources.

While SSO is convenient for users, it presents new security challenges. If a user's primary password is compromised, attackers may be able to gain access to multiple resources. In addition, as sensitive information makes its way to cloud-hosted services it is even more important to secure access by implementing two-factor authentication.

About Duo Single Sign-On

Duo Single Sign-On is our cloud-hosted SSO product which layers Duo's strong authentication and flexible policy engine on top of Webex logins using the Security Assertion Markup Language (SAML) 2.0 authentication standard. Duo Single Sign-On acts as an identity provider (IdP), authenticating your users using existing on-premises Active Directory (AD) or any SAML 2.0 IdP and prompting for two-factor authentication before permitting access to Webex.

Duo Single Sign-On is available in Duo Beyond, Duo Access, and Duo MFA plans, which also include the ability to define policies that enforce unique controls for each individual SSO application. For example, you can require that Salesforce users complete two-factor authentication at every login, but only once every seven days when accessing Webex. Duo checks the user, device, and network against an application's policy before allowing access to the application.

Configure Single Sign-On

Before configuring Webex you'll first need to enable Duo Single Sign-On for your Duo account and configure a working authentication source.

Once you have your SSO authentication source working, continue to the next step of creating the Webex application in Duo.

Download your Cisco Webex metadata file

  1. Log into Control Hub as an administrative user.

  2. Click on Settings in the left-hand navigation bar.

  3. Next to “Authentication” click Modify. A pop-up will appear with new options.

  4. On the “Single Sign-On” page select Integrate a 3rd-party identity provider. (Advanced) and click Next.

  5. On the “Export Directory Metadata” page click Download Metadata File. You'll need this file later.

  6. Leave this page open in a tab, you'll return to it later.

Create the Webex Application in Duo

  1. Log on to the Duo Admin Panel and navigate to Applications.

  2. Click Protect an Application and locate the entry for Cisco Webex (with Control Hub) with a protection type of "2FA with SSO hosted by Duo (Single Sign-On)" in the applications list. Click Protect to the far-right to start configuring Cisco Webex (with Control Hub). See Protecting Applications for more information about protecting applications in Duo and additional application options. You'll need the information on the Cisco Webex (with Control Hub) page under Metadata later.

  3. Upload the metadata file you downloaded earlier to the XML File section.

  4. Webex uses the Mail attribute when authenticating. We've mapped the <Email Address> bridge attribute to Duo Single Sign-On supported authentication source attributes as follows:

    Bridge Attribute Active Directory SAML IdP
    <Email Address> mail Email

    If you are using a non-standard email attribute for your authentication source, check the Custom attributes box and enter the name of the attribute you wish to use instead.

    Duo Webex Application Settings

  5. You can adjust additional settings for your new SAML application at this time — like changing the application's name from the default value, enabling self-service, or assigning a group policy.

  6. Scroll to the bottom of the page and click the Save button.

  7. The XML File section should now display a green checkmark showing that it is configured. You can upload a new XML file in the future to override the existing one.

Duo Universal Prompt

Duo's next-generation authentication experience, the Universal Prompt, is coming to web-based applications that display the current Duo Prompt in browsers.

Migration to Universal Prompt for your Cisco Webex application is a two-step process:

  • Update the Cisco Webex application to support the Universal Prompt.
  • Enable the Universal Prompt experience for users of that Cisco Webex application (when the Universal Prompt becomes available)

We've already updated the Duo Cisco Webex application to support the Universal Prompt when it's ready, so there's no action required on your part to update. The "Universal Prompt" section of this application's details page in the Admin Panel reflects this status today as "New Prompt Ready".

Universal Prompt Info - Application Updated

When the Universal Prompt becomes available, you'll return here to activate it for users of this application.

Click the See Update Progress link to view the Universal Prompt Update Progress report. This report shows the update availability and migration progress for all your Duo applications in-scope for Universal Prompt support.

Read the Universal Prompt Update Guide for more information about the update process to support the new prompt, and watch the Duo Blog for future updates about the Duo Universal Prompt.

Configure Webex SSO in Control Hub

  1. Return to Control Hub as an administrative user.

  2. Continuing from where you were earlier on the “Export Directory Metadata” page click Next.

  3. On “Import IdP Metadata” under “Signing of Metadata” select Allow self-signed certificate in Metadata.

  4. Click Download XML next to the "IdP Metadata file" button on the Webex application's page in the Duo Admin Panel under Downloads to download the Duo Single Sign-On XML file. On the Webex administrative page upload the XML metadata file you downloaded from Duo. Click Next.

  5. On the “Test SSO Setup” page click Test SSO Connection. A new page will open and you’ll be redirected to login with Duo Single Sign-On by completing primary authentication and Duo second-factor. Upon successful login you’ll be taken to a page that says “Single Sign-on succeeded.” Close this window and return to the Control Hub page.

  6. As long as the authentication was successful select The test was successful. Enable Single Sign On. and click Next. If it was not successful, double-check instructions and settings. Do not continue until you get a successful test authentication.

  7. Once the settings successfully save you’ll be returned to the “Settings” page and SSO will be enabled for Webex.

    Webex Single Sign-On Setting Edit

Learn more about Webex SSO at Webex Help.

Verify SSO

You can log on by navigating to Webex Login. Type your e-mail address the text field and click Next. You'll be redirected to the Duo Single Sign-On login page. Enter your primary directory logon information, approve Duo two-factor authentication, and get redirected back to the Webex site after authenticating.

Duo Single Sign-On Login and Authentication Prompt

Congratulations! Your Webex users now authenticate using Duo Single Sign-On.

Users can also log in using their desktop and mobile app clients for Webex Meetings and Webex Teams.

Enable Remembered Devices

To minimize additional Duo two-factor prompts when switching between Webex and your other Duo Single Sign-On SAML applications, be sure to apply a shared "Remembered Devices" policy to your SAML applications.

Troubleshooting

Need some help? Try searching our Knowledge Base articles or Community discussions. For further assistance, contact Support.
